Modula EVO Rotating Laser: a laser system with a rotary table for large-scale marking
The Modula line lasers, in safety class 1, are designed for companies that require large-scale marking, ideal for projects involving the production of thousands of components per month, with partially automated processes and large parts. These systems can be equipped with either Fibre or CO2 sources.
Laser Sources: Fibre; Co2
Marking area: 110×110; 175×175;
Power: 20; 30; 40W
The Modula EVO Rotating Laser is equipped with a rotary table available in three versions with a diameter of 500mm, 800mm or 1200mm. While the laser is marking, the operator can load the pieces on the other side of the table, thus reducing production times and increasing the efficiency of the process.
The system is managed by the Zeus EVO proprietary software, based on 2D CAD, which allows to engrave logos, drawings, serial alphanumeric codes, QRCodes, DataMatrix and Barcodes on a wide range of materials. Our technicians will guide you in choosing the ideal marking solution and offer free trials on your components.
The Modula EVO Rotating Laser complies with the machinery directive and the LASER safety regulations IEC 60825. Our production system is ISO 9001:2015 certified, and the laser marker is one of the facilitated assets of Industry 4.0. At the time of installation, we provide a free training course and offer remote software assistance.
|
LASER SOURCES
Fibra; Co2
|
MARKING AREA
110×110; 175×175
|
MARKING SPEED
6000 MM/SEC
|
NOMINAL WAVELENGTH
20-30-40 W
|
WORKTOP
Tavola Rotante da 500, 800 o 1200 mm
|
DOOR
Automatico + Manuale
|
COOLING SYSTEM
Aria
|
MOTORISED AXES
Z
|
